Nortik ARGO - Frame Insertion and Tensioning

9
Slide the rail to the riveted stopping rings. Make sure, the attachments sit on the rubber
pads.
6) Inserting the frame into the hull and tensioning it
First insert the stern element into the hull.
If needed, twist the frame by doing so, but
make sure to place the frame (ridge bar
and keel) centered!
Lower stringer
element: place
from the
outside!
upper stringer
element: the
attachment faces
inwards!
Lower
stringer element: place
from the outside!
cross rib #2
stopping rings on the stringer
bow
