ENGLISH 8
REPLACING THE BLADE (Continued)
When following the next three steps, use EXTREME CAUTION as the blade is very
sharp! Once the Ice Tray is removed, you are fully exposed to the blade inside!
2. Once the Disassembly Tool is properly inserted, twist counter-clockwise (as the arrow
shows) and lift the Ice Hopper out.
BLADE IS NOW COMPLETELY EXPOSED – USE CAUTION
3. Locate the two plastic clips on the Blade Assembly and use a spoon and your thumb to
press the clips inward and lift out the Blade Assembly.
4. Twist off the Blade Retainer Nut, and using extreme caution, remove the Blade Cartridge
from the Assembly. Insert the replacement Blade Cartridge, and reverse the above
steps to reassemble.
5. After reversing all steps, make sure to lock with the tool.
