Nostalgia CCP400 - Parts & Assembly

ENGLISH
5
PARTS & ASSEMBLY
Hardware
#1 Bolt (10mm)
Qty. 10
#2 Bolt (38mm)
Qty. 2
#3 Bolt (60mm)
Qty. 2
#12 Door Handle
Qty. 1
#13 Sleeve Barrel
Qty. 2
#8 Flat Washer
Qty. 4
#9 Magnet
Qty. 1
#10 Nut Cap
Qty. 10
#11 Nut
Qty. 2
#4 Screw (10mm)
Qty. 4
#5 Screw (15mm)
Qty. 2
#6 Flat Washer (6mm)
Qty. 10
#7 Flat Washer (8mm)
Qty. 8
