PARTS & ASSEMBLY
Please ensure that you have removed all of the hardware and parts listed before
discarding packaging. In our eorts to reduce packaging, we maximize the packing
material to protect your new purchase. As a result, small parts may not be readily visible.
Hardware
#1 Bolt (10mm) #2 Bolt (38mm) #3 Bolt (60mm)
Qty. 10 Qty. 2 Qty. 2
#4 Screw (10mm) #5 Screw (15mm) #6 Flat Washer (6mm) #7 Flat Washer (8mm)
Qty. 4 Qty. 2 Qty. 10 Qty. 8
#8 Locking Washer #9 Magnet #10 Nut Cap #11 Nut
Qty. 4 Qty. 1 Qty. 2 Qty. 2
#12 Door Handle #13 Sleeve Barrel #14 Base Foot
Qty. 1 Qty. 2 Qty. 2
