UDS-4 Installation and user manual PAGE - 5
UDS-4_manu M--203.1-UDS4N-ENG Rev A.1 NOTIFIER ITALIA
CNIN
Num
Name
Notes/Relays
Description
1
INALL1
NA
Alarm 1 (from conventional control unit L1)
(controlled entry)
2
GND
3
INALL2
NA
Alarm 2 (from conventional control unit L2)
(controlled entry)
4
INATTM
NA,[NA|NC].
Device Manual Activation Power Off
(controlled entry)
5
GND
6
INPROLE
NA
Emergency Extension Device
(controlled entry)
7
INMANU
NA
Manual shutdown only
(controlled entry)
8
GND
9
ININTEM
NA
Emergency Interruption Device
(controlled entry)
10
INPRESS
NA,[NA|NC].
Pressure switch
(controlled entry)
11
GND
12
INFLUSS
NA,[NA|NC].
Flow switch
(controlled entry)
2.2 - DESCRIPTION OF INPUTS
The following activation window applies to each input on the terminal board. The only exception is the three inputs flow
switch, pressure switch and manual activation, where it is possible, from the configuration menu (CONF button), to
exchange the rest window with the alarm window (for NC or NO type inputs).
In the default configuration, all inputs are balanced with a 5.4kΩ nominal "End-of-Line" resistor, Rest value, obtained
from the series of two 2.7kΩ resistors. An NO contact is applied to one of the two resistors at rest. The input is activated
when the contact is closed and the nominal resistance drops to 2.7kΩ, the Activation value.
A resistance drift control algorithm is applied to each input, and if the resistance value falls within the resistance ranges
L, M and H, an input level fault '... undetermined low', '... undetermined medium' and '... undetermined high' is provided.
Other faults that can be signalled by an input are: "short-circuited", "open" with obvious meaning, in addition diagnostics
in "fault" and "unstable". In the latter case it means that the input is constantly changing between states but does not
remain there long enough.
Short circuit
L
Activation
M
Rest
H
Cut
1K 1k2 3k8 4k2 6k5 7k
N.B. The maximum number of devices that can be connected to the line (manual override controls, emergency
override and emergency stop controls) depends on the distance from the unit and their power consumption.
