Notifier ID2net User Manual

ID
2
net Installation & Commissioning Manual
13 997-448-000-2, Issue 2
July 2004
Trouble Shooting Guide
NGM PCB instruction sheet (ref: 997-449) for
correct jumper link setting.
ID
2
net: Channel 2 Link Fault
See Channel 1 Link Fault above.
ID
2
net: Flash Checksum Error
This message indicates a NGM PCB failure.
Action: Replace the NGM PCB.
Note: Other fault conditions may occur in
exceptional circumstances. If this
happens, contact your supplier for
guidance.
5.2 Reconfiguration Warning
Messages
If a panel has already been configured as part
of a Master/Slave network and an attempt is
made to configure it as an ID
2
net peer-to-peer
network, a warning message is displayed as
follows:
WARNING: this panel is already configured
as a member of a Master/Slave network.
This is incompatible with ID
2
net Peer-to-
Peer Network.
If a panel has already been configured as part
of a ID
2
net peer-to-peer network and an
attempt is made to configure it as an Master/
Slave network, a warning message is
displayed as follows:
WARNING: this panel is already configured
as a member of a ID
2
net Peer-to-Peer
Network. This is incompatible with Master/
Slave network.

Notifier ID2net Specifications

General

Brand	Notifier
Model	ID2net
Category	Network Hardware
Language	English

Summary

Introduction to ID²net

Software Compatibility

Details ID et compatibility with ID3000 Series panels and software versions.

Software Version

Explains how to view panel, Loop PCB, and ID net software versions using Lamp Test.

Functional Description of ID²net

Network Topology

Describes how fire control panels are networked as a complete and continuous loop.

Installation of ID²net System

Hardware Requirements

Lists required hardware for ID3000 Series panels, including NGM and Fibre-optic Interface PCBs.

Network Gateway Module PCB Installation

Details fitting and configuration of the Network Gateway Module (NGM) PCB.

Fibre-optic Interface PCB Installation

Explains requirement and fitting of the Fibre-optic Interface PCB for optical-fibre cables.

Earth Fault Detection

Explains jumper links for enabling/disabling earth fault monitoring on network links.

Cables for Network Links

Recommends cable types and guidelines for ID net network installation, including copper and fibre optics.

Fibre-optic Cable Specifications

Specifies connector style, link type, wavelength, and fibre type for ID net fibre-optic links.

Configuring Panels on the Network

Off-line Configuration Tool

Mentions the ID3000 Off-line Support Tool for off-line configuration preparation.

Assigning Panels to the Network

Explains how to assign a discrete network node identifier to each panel on the network.

Location Text Configuration

Guides on entering a panel location description using the text editing screen.

Repeaters Configuration

Describes the procedure for configuring repeaters on networked panels using the RS485 communications link.

Trouble Shooting Guide

Fault Messages - Possible Causes and Remedies

Lists common fault messages like 'Network card missing' and 'Network startup fault' with actions.

Reconfiguration Warning Messages

Explains warning messages when attempting to configure incompatible network types (Master/Slave vs. Peer-to-Peer).
