Notifier INA User Manual

INA 15092:I 05/30/01
17
50 Feet (15.24 m) Max
(Typical)
Wiring Distance Limited by
Cable Capacitance. Refer to
the EIA-232 Standard.
4
nc
Twisted-Pair
Twisted-Pair
TB3- 3
(+)
and
TB3-4 (-)
Keltron Printer
Model No. VS4095/5
+ DC IN
DC IN -
Figure 2.3-4 Keltron Printer Connections
TB2-6
TB2-5
TB2-6
TB2-4
EIA-232 Reference
Transmit to Printer
EIA-232 Reference
Ready/Busy from Printer
MPS-24A/
MPS-24AE
Main Power Supply
Keltron Printer
Model No. VS4095/5
INA Connector TB2
Figure 2.3-5 Ancillary Connections
Plug this DB-25 Connector into the EIA-232 Port
of the PRN Printer.
PG-ancillary.wmf
TB2 on
the INA
