DISPLAY SYSTEM CONFIGURATION
Selecting 1 from the Read Status Menu allows the operator to review the various system parameters entered into the INA
from the following System Configuration Menu:
READ
STATUS
MENU OPTION 1
1.2 READ STATUS
The Read Status feature provides local INA and network device status information. If a new event, such as an alarm or
trouble message, is received by the INA during Read Status, the Read Status function will be aborted and the event will
be displayed. To execute Read Status:
Enter 1 for Display System Configuration. This selection provides information on any of the system parameters pro-
grammed into the INA, such as NFN node address, MIB-W communication thresholds, keyswitch enabled, annunciator
modules installed, etc.
Enter 2 for Point Read. This selection provides information on the status of any annunciator point programmed into the
INA.
Enter 3 for Network Point Read. This selection provides information on the status of any device or zone on the network.
Only devices and zones on nodes that have been programmed into the INA can be accessed under the Read Status
command.
Note: Read Status is not supported on the AFP-200.
PRESS@1=PSYS,2=PTREAD,3=NETPTREAD
:
A
READ
STATUS
Press and the display will show:
A
READ
STATUS
PRESS@1=NFN,2=KEY,3=CABLE,4=ANN,5=UDACT,
6=EXTEQ,7=LOCP :
