Nova COMET 14DR User Manual

3
127-0919-001
Lathe Specifications
Metric
Imperial
Swing Over Bed
177.8mm
7”
Distance Between Centres
469.9mm
18.5”
Swing Over Tool Rest Base
285.75mm
11.25”
Maximum distance
Tool rest to spindle centre
217.49mm
8.5625”
Floor to Centre Height
381mm
15”
Overall Size
920mm(l) x 330mm(w) x 510mm(h)
32.7” (l) x 12.99” (w) x 20” (h)
Footprint
822.32mm (l) x 215.9mm(w)
32.375” (l) x 8.5” (w)
Weight
47 Kg
103.61 lb
Headstock
Spindle Thread
1” x 8TPI (Right Hand Thread)
Headstock Spindle Taper
Morse Taper #2 (MT2)
Spindle Bore
10.31mm
13/32” or .40”
Tailstock
Quill Taper
Morse Taper #2 (MT2)
Tool Rest
Width
152.4mm
6”
Shaft Diameter
25.4mm
1”
Post Length
88.9mm
3.5”
Base Height
84.14mm
3.3125”
Construction
Bed
Precision – Ground Cast Iron
Frame
Cast Iron & Steel
Headstock
Cast Iron & Steel
Tailstock
Cast Iron & Steel
Pain Type/ Finish
Enamel/Powder Coat
Other Specification
Bed Width
203.2mm
8”
Faceplate Size
80mm
3 - 9/64”
Electrical Specifications
Input Voltage
120V
Input Frequency
60Hz
Full Load Input
Current Rating
7.3A
Power Input Plug Type
NEMA 5-15P
Motor Specifications
Motor Type
Universal Brush Type
Motor power output
0.75KW (1HP)
Motor speed
1400 RPM
Phase
Single Phase
Input Current
7.3A
IMPORANT NOTE
Due to NOVA’s continuous product improvement and development policy, specifications, features and images contained in this manual may change without
notice. Teknatool is not responsible for omissions or errors herein or for incidental damages in connection with the furnishing of this information.

Nova COMET 14DR Specifications

General

Brand	Nova
Model	COMET 14DR
Category	Lathe
Language	English
