Nova IN8 User Manual

7. Technical Data / Technische Daten
MODEL
System Type:
Frequency Range (-10 dB):
Frequency Response (±3 dB):
Coverage Pattern:
HF Horn:
Crossover Modes:
Crossover Frequency:
Power Rating
(Continuous** / Program / Peak):
Maximum SPL***:
System Sensitivity (1w/1m):
LF Driver
LF Nominal Impedance:
MF Driver:
MF Nominal Impedance:
HF Driver:
HF Nominal Impedance:
Active Tunings:
Enclosure:
Suspension / Mounting:
Transport:
Finish:
Grille:
Input Connectors:
Dimensions (W x H x D):
Net Weight:
Optional Accessories:
MODEL
System Type:
Frequency Range (-10 dB):
Frequency Response (±3 dB):
Coverage Pattern:
HF Horn:
Crossover Modes:
Crossover Frequency:
Power Rating
(Continuous** / Program / Peak):
Maximum SPL***:
System Sensitivity (1w/1m):
LF Driver
LF Nominal Impedance:
MF Driver:
MF Nominal Impedance:
HF Driver:
HF Nominal Impedance:
Active Tunings:
Enclosure:
Suspension / Mounting:
Transport:
Finish:
Grille:
Input Connectors:
Dimensions (W x H x D):
Net Weight:
Optional Accessories:
IN 8
8 x 3", two-way, compact line array
82 Hz - 20 kHz
92 Hz - 18 kHz
100° x 25° nominal
Waveguide horn
Passive
4.5 kHz
Passive: 440 W / 880 W / 1.760 W
123 dB SPL peak
97 dB SPL
8 x NOVA 3/60ND
4 ohms (passive)
n/a
n/a
1 x NOVA NRD101, ribbon driver
4 ohms (passive)
High pass filter (Buttherworth / 24 dB) recommended
Fullrange, 12 mm, plywood (multi layer)
Tripod Adapter 35mm
n/a
Black NOVA PolyCoat finish
Powder coated, black, perforated steel,
NOVA logo
2 x Neutrik© Speakon© NL4
1+/1- (2+/2- linked from input to output)
130 mm x 845 mm x 132 mm
7 kg
FP1: Flexible tilt / pitch (Article number: # 80035)
IWK: Wall mount kit (Article number: # 20060)
SG1: T-bar for use of 2 speakers on a box stand (# 80018)
IB8: Bag for IN8 (# 20073)
IN 315 SUB (active subwoofer)
1 x 15" neodym, bass-reflex, subwoofer
34 Hz - 300 kHz
38 Hz - 270 kHz
Omni
n/a
Variable, integrated DSP
Variable, integrated DSP
Bi-Amped LF: 1.000 W (RMS) amplifier power
Bi-Amped MF/HF: 2 x 440 W (RMS) amplifier power
129 dB SPL peak
99 dB SPL
1 x NOVA 15/700 N/D
8 ohms (active)
n/a
n/a
n/a
n/a
120 Hz (integrated DSP)
Subwoofer, 15 mm, plywood (multi layer)
2 x M20 pole socket
8 x integrated handles
Black NOVA PolyCoat finish
Powder coated, black, perforated steel with acoustic
Transparent charcoal foam backing, NOVA logo
Analog input: 2 x XLR female, digtal input: XLR female + 1 x XLR LINK,
Powered outputs: 3 x NL4 Speakon© NL4, Aux output: 1 x XLR Male
420 mm x 600 mm x 540 mm
26.5 kg
ROD1: Distance Rod (Article number: # 80016)
IB15: Bag for IN315SUB (# 20083)
URC1: Converter USB / RS485 (# 20065)
IN 15 SUB P (passive subwoofer)
1 x 15" neodym, bass-reflex, subwoofer
34 Hz - 300 kHz
38 Hz - 270 kHz
Omni
n/a
n/a
n/a
Passive: 700 W / 1.400 W / 2.800 W
129 dB SPL peak
99 dB SPL
1 x NOVA 15/700 N/D
8 ohms (passive)
n/a
n/a
n/a
n/a
120 Hz (recommended)
Subwoofer, 15 mm, plywood (multi layer)
2 x M20 pole socket
8 x integrated handles
Black NOVA PolyCoat finish
Powder coated, black, perforated steel with acoustic
Transparent charcoal foam backing, NOVA logo
2 x Neutrik© Speakon© NL4
2+/2- (1+/1- linked from input to output)
420 mm x 600 mm x 540 mm
23.5 kg
ROD1: Distance Rod (Article number: # 80016)
IB15: Bag for IN15SUBP (# 20083)
