Page #2 background image
SuperNova2 – Disassembly
Tools Required:
1. External Circlip Pliers
2. Flat Head Screw Driver
3. Disposable Rag
STEPS DESCRIPTION IMAGE
1.
Place chuck face down. The jaw slides can
be at any position.
2.
Use the external snap ring plier to remove
the retaining ring (as shown in the image).
Continues to next page…
