Nova TITAN

Chucks Parts List
SKU
Thread
Size
PARTS LIST
SKU 48111
Precision Midi
Direct Thread
1” x 8 TPI
1. 48100 Chuck Bod
y
2. 48116 Scroll Rin
g
3.
23051
23052
23053
23054
Jaw Slides
4. EC48
36mm External
Circlip
SKU 48232
G3 Direct Thread
1” x 8 TPI
1.
48206 (Insert)
48207 (Direct)
Chuck Body
2. 23082 Scroll Ring
3.
23051
23052
23053
23054
Jaw Slides
4. EC48 External Circlip
SKU 48202
G3 Insert Type
M38 x 3.5
SKU 23062
SuperNOVA2
Direct Thread
1 ¼” x 8tpi
1.
23049 (Insert)
23061 (M33)
Chuck Body
2. 23048 Back Cover
3. 23082 Scroll Ring
4.
23051
23052
23053
23054
Jaw Slide #1~#4
5. 23081 Pinion Gear
6. EC48 External Circlip
SKU 23055
SuperNOVA2
Insert Type
M38 X3.5
SKU 13060 –
Titan III
Direct Thread
1 ¼” x 8tpi
1.
13038 (Normal)
13039
(
Europe
)
Chuck Body
2. 13003 Back Cove
r
3. 13035 Scroll Rin
g
4.
1339011
1339012
1339013
1339014
Jaw Slide #1~#4
5. 13036 Pinion Gear
6. EC48 External Circlip
7. 13004 Fastening Screw
8. LSM4N Position Screw
SKU 13061 –
Titan III
Europe Version
Direct Thread
M33 x 3.5
p.26
