Introduction
Congratulations on your purchase of a X Series audio power amplifier. We would like to
thank you for your confidence in us and our products.
All the components were specially selected. Although the amplifier was designed to allow
straightforward and uninterrupted operation, improper handling or incorrect installation
could damage the power amplifier.
Your amplifier represents the latest technology in power amplifier design. Please read this
manual carefully as it contains information vital to the safe operation of your amplifier.
Unpacking
Check the carton box and its contents immediately to see if there is any sign of damage.
Upon unpacking inspect the amplifier, if you detect any damage inform the forwarding agent
without delay and ask for the damage to be documented.
Claims can only be made against the forwarder agent by the consignee.
Be sure to save the carton and all packaging materials for the carrier's inspection.
It's a good idea to save the carton and packing material even if the amplifier has arrived in
good condition. Should you ever need to ship the unit back to service office, or one of its
Service Center . Using only the original factory packaging will be the best way to save the
unit from carrier negligence.
Installation/Mounting
The X6000 is 3- rack space units that can mount in a standard 19" rack. Four front panel
mounting holes are provided.
Rear mounting ears give additional support especially important in mobile sound systems.
The unit should not to be installed in a location with:
Too high ambient temperature, dust build-up or excessive humidity;
Fog machines output's oriented to the area of the amplifier;
Exhaust air ventilators and similar units near the area of the amplifier;
With permanent vibrations;
With excessive induction or magnetic fields due to transformers and transmitters;
The Show Always Goes On
X6000 is completely protected against every possible error in operation and is designed to
work under every condition. It gives you maximum power with maximum safety and
increases long-term reliability. Anticipating potential problems at the design stage means
your show always goes on!
SPECIFICATIONS
MODEL
Max output power
RMS at 1 kHz and 1% THD
8 per channel (Watt)
4 per channel (Watt)
2 per channel (Watt)
8 bridged (Watt)
4 bridged (Watt)
THD at 1 kHz and 1 dB below clipping
Slew rate
Dampping Factor
Sensitivity
Input connectors
Link connectors
Mode Switch
Output Connector
Operation voltage
Soft Start
Dimensions ( W x D x H )
Unit ( mm )
Packing ( mm )
Weight ( kg )
Net Weight
Gross Weight
X6000
1750
3000
4500
6000
9000
0.10%
45V/ s
600
26dB/32dB/1.4V
XLR Female
XLR Male/Phonejack
Stereo/Bridge/Parallel
Speakon
230V
Yes
483 x 446 x 133.4
560 x 560 x 195
35
38
(Note-1.Max output @4ohms bridge with burst signal 100ms)
