Nova X Series User Manual

POWER
ON
OFF
High Precision Professional Power Amplifier
Clip
Signal
Protect
Active
Clip
Signal
Protect
Active
Channel 1
0dB0dB
00 00
Channel 2
0dB0dB
00 00
2
1
2
3
4
5
6
7
Reference Manual
Page 4
Reference Manual
Page 9
Front Panel
Rear Panel
1. Rack mounting ears
Two front panel mounting holes are provided on each mounting ear.
2. Input attenuator
Two front panel precision 41 steps input attenuator adjust level for their respective amplifier
channels. Minimum attenuation (-0dB) equals maximum output. In the bridge mode both level
attenuator must be at the same position. We recommend that you set CH1 to the -0dB (full)
position.
3. Signal bar LED
Each channel has a signal LED, as the input signal strength increase, the green SIGNAL indi-
cators light respectively.
4. Clip/Limiter LED
Each channel has a LED that light at the real clipping point (more than 0.5% T.H.D.) and also
indicates the input signed is compressed by amplifiers.
Series SeriesSeries Series
13
121110
13 15 8
1110
14
9 9
9 9
BRIDGE
PARALLEL
STEREO
Bridge Mono Mode
CAUTION: TURN OFF AMPLIFIER
BEFORE CHANGING THIS SWITCH
LOUDSPEAKERS
MIXER
Only use the CH 1 Input
CH 2 is not used in the mode
CHANNEL 1
CHANNEL 2
LOUDSPEAKERS
CH 1
CH 2
MIXER
CAUTION: TURN OFF AMPLIFIER
BEFORE CHANGING THIS SWITCH
Stereo Mode
BRIDGE
PARALLEL
STEREO
LOUDSPEAKERS
MIXER
Only use the CH 1 Input
CH 2 is not used in the mode
CAUTION: TURN OFF AMPLIFIER
BEFORE CHANGING THIS SWITCH
Parallel Mono Mode
CHANNEL 1
CHANNEL 2
BRIDGE
PARALLEL
STEREO
Figure 1
Parallel Inputs (Link)
