FX Modulation Matrix – sources
The table below lists the sources of modulation available to Inputs A and B of each Slot in
the FX Modulation Matrix.
Display Controlling Source
Direct
The Depth control
ModWheel
Mod Wheel
AftTouch
Keyboard aftertouch
ExprPED1
Expression pedal connected at PEDAL 1 input
BrthPED2
Expression pedal connected at PEDAL 2 input
Velocity
Keyboard velocity
Keyboard
Key position on keyboard
Animate1
Animate Button 1
Animate2
Animate Button 2
CV +/-
CV input varies controlled parameter both positively and negatively
Lfo 3 +
LFO 3 waveform varies controlled parameter in a positive sense
Lfo 3 +/-
LFO 3 waveform varies controlled parameter both positively and
negatively
Lfo 4 +
LFO 4 waveform varies controlled parameter in a positive sense
Lfo 4 +/-
LFO 4 waveform varies controlled parameter both positively and
negatively
BndWhl+
Pitch Bend wheel up increases parameter
BndWhl-
Pitch Bend wheel up decreases parameter
FX Modulation Matrix – destinations
The table below lists the destinations to which each Slot of the FX Modulation Matrix may
be routed.
Display Controlled Parameter
Dist Lev
Distortion Level
Chor Lev
Chorus Level
ChorRate
Chorus Rate
Chor Dep
Chorus Depth
Chor FB
Chorus Feedback
Del Lev
Delay Level
D el Tim e
Delay Time
Del FB
Delay Feedback
Rev Lev
Reverb Level
R ev Tim e
Reverb Time
Rev LPF
Reverb Low Pass
Rev HPF
Reverb High Pass
MIDI parameters list
Parameter
CC/
NRPN
Control
Number.
Range
Default
Value
Patch Category NRPN 0:0 0 -14 0
Patch Genre NRPN 0:1 0-9 0
Voice Mode NRPN 0:2 0-4 3
Voice Unison NRPN 0:3 0-4 0
Voice Unison Detune NRPN 0:4 0-127 25
Voice Unison Spread NRPN 0:5 0-127 0
Voice Keyboard Octave NRPN 0:6 61-67 (-3 to +3) 64 (0)
Glide Time CC 5
0-127
(0 to +127)
0 (60)
Voice Pre-Glide NRPN 0:7
52-76
(-12 to +12)
64 (Off)
Glide On CC 35 0-1 (0 to +1) 0 (0)
Oscillators
Osc Common
Divergence
NRPN 0:9
0-127
(0 to +127)
0 (0)
Osc Common Drift NRPN 0:10
0-127
(0 to +127)
0 (0)
Osc Common Noise
LPF
NRPN 0 :11
0-127
(0 to +127)
127
Osc Common Noise
HPF
NRPN 0:12 0-0 ( to+) (0)
Oscillator 1 Range CC 3 63-66 (-1 to +2) 64 (0)
Oscillator 1 Coarse CC pair 14,46
0-255
(-128 to +127)
128 (0)
Oscillator 1 Fine CC pair 15,47
28-228
(-100 to +100)
128 (0)
Oscillator 1
ModEnv2 > Pitch
CC 9
1-127
(-63 to +63)
64 (0)
Oscillator 1
LFO2 > Pitch
CC pair 16,48
1-255
(-127 to +127)
128 (0)
Oscillator 1 Wave NRPN 0 :14 0-4 (0 to +4) 0 (2)
Oscillator 1 Wave More NRPN 0:15 4-63 (4 to +63) 0 (4)
Oscillator 1
Shape Source
NRPN 0:16 0-2 (0 to +2) 0 (0)
Oscillator 1
Manual Shape
CC 12
0-127
(-64 to +63)
64 (0)
Oscillator 1
ModEnv1 > Shape
CC 119
0-127
(-64 to +63)
64 (0)
Oscillator 1
LFO1 > Shape
CC 33
0-127
(-64 to +63)
64 (0)
Oscillator 1 Vsync CC 34
0-127
(0 to +127)
0 (0)
Oscillator 1
Saw Density
NRPN 0:17
0-127
(0 to +127)
0 (0)
Oscillator 1 Saw
Density Detune
NRPN 0:18
0-127
(0 to +127)
0
Oscillator 1 Fixed Note NRPN 0:19 0-88 (0 to +88) 0 (Off)
Oscillator 1
Bend Range
NRPN 0:20
40-88
(-24 to +24)
76
Oscillator 2 Range CC 37 63-66 (-1 to +2) 64 (0)
Oscillator 2 Coarse CC pair 17,49
0-255
(-128 to +127)
64
Oscillator 2 Fine CC pair 18,50
28-228
(-100 to +100)
64
Oscillator 2
ModEnv2 > Pitch
CC 38
1-127
(-63 to +63)
64 (0)
Oscillator 2
LFO2>Pitch
CC pair 19,51
1-255
(-127 to +127)
64
Oscillator 2 Wave NRPN 0:23 0-4 (0 to +4) 0 (2)
Oscillator 2 Wave More NRPN 0:24 4-63 (4 to +63) 4 (4)
Oscillator 2
Shape Source
NRPN 0:25 0-2 (0 to +2) 0 (0)
Oscillator 2
Manual Shape
CC 39
0-127 (-64 to
+63)
64 (35)
Oscillator 2
ModEnv1 > Shape
CC 40
0-127 (-64 to
+63)
64 (0)
Oscillator 2
LFO1 > Shape
CC 41
0-127 (-64 to
+63)
64 (0)
Oscillator 2 Vsync CC 42
0-127 (0 to
+127)
0 (0)
Oscillator 2
Saw Density
NRPN 0:26
0-127
(0 to +127)
0 (0)
(Continues...)
