4
COMPONENTS
1
Carrying handle
2
Float height adjustment
3
Cable and plug
4
Float
5
Hose adapter
for pressure connection
6
Pump casing
OPERATION
Attach a suciently long and strong rope to the handle before rst use. The pump
is submerged into the liquid on this holding rope and can also be carried with it as
well as with the handle.
Note: In the case of continuous use of the pump with the rope,
the condition of the rope must be checked regularly as it can
decay and break over time.
• Connect pressure pipe.
• For occasional use, use a suitable water hose.
• The use of rigid pipes with a non-return valve is recommended for use at a xed
location. This prevents return ow of the liquid when switching o ( Threaded
connection: see technical date, page 7).
• Screw pressure line onto the pressure connection.
• All threaded connections must be sealed with thread sealing tape
(e.g.: Teon
®
tape).
• When using a hose, screw a suitable hose adapter onto the pressure connection.
• Push the hose rmly onto the hose adapter and secure with hose clamp.
1
6
2
4
5
3
