Novoferm HAD MS - Inspection and test log book for the door system; Check list of door system; Testing of door system

Inspectionandtestlogbookforthedoorsystem
Testingofdoorsystem
Owner/operatorofthe
system:
Locationofdoorsystem:
Operatordata:
Operatortype:
Manufacturer:
Dateofmanufacture:
Operatingmode:
Doordata:
Type:
Serial no.:
Door dimensions:
Year of construction:
Leaf weight:
Installationandinitialoperation
Company, installer:
Initial operation on:
Name, installer:
Signature:
Otherdetails
Subsequentalterations
Retain these installation, operating and maintenance instructions for the full duration of the operator’s service life!
GB
Retain these installation, operating and maintenance instructions for the full duration of the operator’s service life!
GB
General information
When being put into service power-
operated doors must be inspected
and maintained by correspondingly
qualified persons (persons with
suitable training and qualifications
b a s e d o n kn o w l e d g e a n d
experience) at intervals as specified
in the manufacturer's maintenance
instructions and, if necessary, also
in accordance with any special
national regulations (e.g. BGR 232
"Guidelines for Power-operated
Windows, Doors and Gates").
All inspections and maintenance
carried out must be documented in
the inspection log book provided. It
must be kept safe by the owner-
operator, together with the
documentation on the door system,
throughout the operator's entire
service life and must be filled out in
full and handed over to the owner-
operator by the installer at the latest
at the time of putting into service.
(We also recommend this for
manually operated doors.)
It is absolutely imperative that the
gu id el in es p ro vi de d in t he
documentation accompanying the
door system (Installation, Operating
and Maintenance Instructions etc.)
are adhered to.
The manufacturer's guarantee
becomes null and void in the event
that inspection / maintenance has
not been properly carried out.
Alterations to the door system (in as
far as permitted) must also be
documented.
Caution: An inspection is the
same as maintenance!
not
Checklistofdoorsystem
(Documenttheequipmentpresentatthetimeofinitialoperationbytickingoff)
Equipment present Features to be tested Remark
applicable
1.0 Door
1.1   ________________________Manual operation of the door Smooth running
1.2  /  ________________________Fastenings / connections State Seat
1.3  /  ________________________Pivots / joints State Lubrication
1.4  /  ________________________Track rollers / track roller holders State Lubrication
1.5  /  ________________________Seals / sliding contact strips State Seat
1.6  /  ________________________Door frame / Door guide Alignment Fastening
1.7  /  ________________________Door leaf Alignment State
2.0 Weightcounterbalance/safeopening
2.1  / /  ________________________Springs State Seat Setting
2.1.1   ________________________Clamping heads / bearing blocks State
2.1.2  /  ________________________Spring safety device State Data plate
2.1.3  /  ________________________Safety elements State Seat
2.2  /  ________________________Wire cables State Seat
2.2.1  /  ________________________Cable fastening State Seat
2.2.2   ________________________Cable drums 2 safety windings
2.2.3   ________________________/ /Slack cable switch State Seat Function
2.3   ________________________Anti-fall safeguard State
2.4   ________________________Concentricity of T-shaft State
3.0 Operator/controls
3.1  /  ________________________Operator / support bracket State Fastening
3.2   ________________________Electrical cables / connections State
3.3  /  ________________________Emergency release State Function
3.3.1  /  ________________________Quick chain State Function
3.3.2  /  ________________________Crank handle State Function
3.3.3   ________________________/Quick release State Function
4.0 Safeguardingofcrushandshearingzones
4.1   ________________________Force limit Stops and reverses
4.2   ________________________Safeguards to prevent persons Door leaf
from being lifted up by the door
4.3   ________________________Site conditions Safety distances
5.0 Otherdevices
5.1  /  ________________________Latching / lock State Function
5.2  /  ________________________Wicket door Function State
5.2.1  /  ________________________Wicket door contact Function State
5.2.2  /  ________________________Door closer Function State
5.3  /  ________________________Traffic light control Function State
5.4  /  ________________________Photocells Function State
5.5  /  ________________________Safety edge Function State
6.0 Documentationoftheoperator/owner
6.1  /  _______________________Data plate / CE marking complete readable
6.2  /  ________________________Door system's declaration complete readable
of conformity
6.3  /  ________________________Installation, Operating and complete readable
Maintenance Instructions
3.4   ________________________/Control devices, State Function
push-button / hand transmitter
3.5   ________________________/Travel cut-out State Function
