Setup
Engage trolley brakes to
stabilise system prior to use.
Carefully attach monitor
to trolley and fully tighten
clamp.
Connect power supply to
suitable rated mains outlet.
Press power button to start
system.
Once zero test is complete,
follow instructions on screen
to set-up system.
Experienced users may
choose to skip directly to
system tests or skip to dose.
System test circuit set-up:
NOxFlow
TM
arrow points in
direction of ow. 1m vent
tubing between sample
point and NOxFlow
TM
.
Perform system
test to ensure correct system
functionality prior to
connecting to patient.
Connect to patient circuit;
sample near patient Y-piece.
Retain NOxFlow
TM
orientation for ow and 1m
distance from sample point.
1 2
3
4
5
6 7
8
