FRAME SIZE RECOMMENDATIONS
note on sizing: we recommend the M size for 170 – 182cm and the L size for riders over 180cm.
TECHNICAL SHEET / SPECS
DEFINE 150
rear wheel travel: 155mm
recommended fork travel: 150-160mm
frame material: carbon fibre
rear shock: 205x65mm
mounting hardware: 20 x 8 mm, trunion
cable routing: semi-internal
head tube: tapered 1.5 IS (IS 42 / IS 52)
headtube length: M size: 120mm, L: 130mm
(headset included)
fits forks with standard 1-1/8” or tapered 1.5 - 1-1/8”
hub spacing 148 x 12mm, NS axle included
post-mount direct 180mm disc brake mount,
max rotor size: up to 200mm
BB: PF92
biggest chainring: up to ~36t
rear derailleur: removable hanger included
seat post/clamp: 31.6mm / 34.9 (clamp included)
stealth cable route in seat tube for dropper post
maximum tire size recommended: 29” x 2.5”, depends
on tire manufacturer
DEFINE 130
rear wheel travel: 130mm
recommended fork travel: 140-150mm
frame material: carbon fibre
rear shock: 185x55mm
mounting hardware: 20 x 8 mm, trunion
cable routing: semi-internal
head tube: tapered 1.5 IS (IS 42 / IS 52)
headtube length: M size: 120mm, L: 130mm
(headset included)
fits forks with standard 1-1/8” or tapered 1.5 - 1-1/8”
hub spacing 148 x 12mm, NS axle included
post-mount direct 180mm disc brake mount,
max rotor size: up to 200mm
BB: PF92
biggest chainring: up to ~36t
rear derailleur: removable hanger included
seat post/clamp: 31.6mm / 34.9 (clamp included)
stealth cable route in seat tube for dropper post
maximum tire size recommended: 29” x 2.5”, depends
on tire manufacturer
