4
®
This appliance is for household use only. Any servicing other than cleaning and
user maintenance should be performed by authorized service representative.
Do not immerse the unit in water. To reduce the risk of fire or electric shock, do
not remove the housing. No user serviceable parts inside. Only authorized service
personnel shall handle repair work.
If the supply cord is damaged, it must be replaced by the manufacturer or its
service agent or a similar qualified person in order to avoid a hazard.
1. Ensure the power cord goes through the hole
created by the front & back base plates when
joined together.
2. Make sure the holes of front base plate correspond
with the rear base, and then press them together.
3. Insert the Oscillation support into the base plate.
4. Fasten the Butterfly screws to make sure the main
unit and the base plates are firmly connected.
5. Then clip the power cord into base plate.
Caution
Assembly of the Fan
