⑨StartSwitch
Startsandstopsmotorrotation
⑩Forward/ReverseSwitch
Thisswitchcontrolsthedirectionofrotation,
forward(FWD)orreverse(REV).Withthecutting
toolfacingtheoperatorrighthandrotation(FWD)
willbeclockwiserotation.
⑪ControllerSwitch(AUTOーMANUAL)
Thisswitchselectsmotor/spindlecontrolfromthe
ControlPanelorfromanexternalsource.
●MANUAL:ControlPanel
●AUTO :Externalcontrolthroughtheinput/
outputconnectorCN2②
⑫MotorSpeedSelectionSwitch
Selectthemotorspeedcontrolmode.Internalunit
(INT),External(EXT),Centering(500)
⑬SpeedAdjustmentKnob
Steplesslyadjustablespeedcontrol.Iftheknobis
turnedclockwise,thiswillincreasemotorspeed.
Motorspeedisadjustable:2,000-40,000min
-1

(400Z),2,000-50,000min
-1
(500Z)and20,000-
80,000min
-1
(800Z).

⑭DigitalSpeedIndicator(SPEED)
PresetSpeed,ActualSpeed,WarningandError
Codesaredisplayedto2digits.
ErrorLamp：Whenanerrorexiststhislamplights
andtheerrorcodeisshownonthedigitaldisplay.
PowerLamp：PowerSwitchisintheONposition.
MotorLamp：Motorisrotating(exceptatthe
minimumofspeedadjustmentknob)
FWD.Lamp：Forwardrotationiscounter-clockwise
rotationwhenthecuttingtoolisfacingtheoperator.
REV.Lamp：Reverserotationisclockwiserotation
whenthecuttingtoolisfacingtheoperator.
ManualLamp：Manualoperation
AUTOLamp：Autooperation
500Lamp：500min
-1
operationforcentering
EXTLamp:MotorControlbyexternalsignal
source.
INTLamp:MotorControlbyfrontpanelcontrols.
LoadMonitorLamp(LOAD):Realtimeload
monitoringdisplay.
（  ）   
⑩Forward/ReverseSwitch
⑪ControllerSwitch（AUTOーMANUAL）
⑨StartSwitch
⑬SpeedAdjustmentKnob
ＢPowerLamp
ＧAutoLamp
ＡErrorLamp
ＣMotorLamp
DFWD.Lamp
ＥREV.Lamp
ＦManualLamp
ＫLoadMonitorLamp(LOAD)
Ｉ ExternalLamp
Ｈ500Lamp
ＪInternalLamp
⑭DigitalSpeedIndicator(Speed)
⑫ MotorSpeedSelectionSwitch

A
B
C
D
E
F
G
H
I
J
K
