NSK NLX nano User Manual

4
2. Motor
2-1 Connecting / Disconnecting the Motor and the Motor Cord
Align and insert firmly the motor pin into the pin holes of the Motor Cord
Connector, and fasten the Motor Cord Nut securely.
(
Fig. 1
)
To remove the Motor Cord from the Motor, unscrew and detach the Motor Cord
Nut, and gently pull out the Motor Cord Connector.
2-2 Connectioning / Disconnecting the motor and the handpiece
(
Option
)
To insert the E-type handpiece in the Motor Insert, align handpiece and Motor,
then turn those until its click.
(
Positioning pins are aligned
)
To remove the handpiece, simply pull out the handpiece from the Motor.
Motor
Motor Cord Connector
Motor Cord
Handpiece is not included.
Fig. 1
Fig. 2
Handpiece (
Option
)
Motor Insert
Positioning Pin
