Manual4094131(Rev.112211)
7
PREDATOR CXH 500 PART LIST
Item Part No. Qty Description
1 4092271 1 Switch plate
1A 4093311 1 Overlay label
2 4092291 1 Switch, vacuum, DPDT
3 4092281 2 Switch, pump & heat, DPST
5 4092431 1 Deck plate & clear lid
7 4093421 1 Vacuum inlet hose barb
8 4092181 1 Recovery tank
9 4093301 1 Label, NSS
10 4092241 1 Dump valve
11 9122330 1 Wing nut, 3/16
12 4092491 1 Quick disconnect, male 1/4
13 4092071 2 Caster, 4 inch
14 4092141 2 Wheel, 10 inch
15 4092151 2 Axle cap
16 4094181 1 Power cord, pump & vac (& heat)
17 4092161 1 Base compartment
18 4092171 1 Solution tank
19 4092351 1 Cord wrap
20 4092691 1 Gauge, pressure reading
21 4092971 1 Pressure regulator, psi adjust
22 4093261 1 Label, serial number & model
23 4093361 2 Strain relief, power cords
26 4094151 2 Vacuum motor, 2-stage, 240V
27 4092191 1 Muffler assembly
28 4092411 1 Elbow/hose barb
30 4092511 1 Filter, in line, pump inlet
31 4092441 1 Elbow assembly, PVC
34 4094161 1 Pump assembly, 500 psi, 240V
38 4092091 1 Plate, mounting
40 4092371 1 Hose, blue, to outlet 20 inch
41 4092621 1 Heater, heated only, 240V
NOT SHOWN
4093321 15 ft solution hose assembly
4093341 15 ft vacuum hose
4093441 Ball float, vac shut-off
4092551 Vac inlet assembly
4093391 Heater repair kit
4092951 Pump rebuild kits
4092731 Pressure regulator rebuild kit
4092721 Fuse, 5 amp, in-line
