INSTALLATION & OPERATION MANUAL
20 | P a g e w w w . n t e n g i n e e r s . i n
7. LCD Update Time
This setting lets you adjust the time frequency in milliseconds that the data on the LCD is
refreshed on the THC LCD Graphic display.
8. Z Speed
This settings lets the user adjust the Z axis speed in mm/ second.
9. Z Acceleration
This settings lets the user adjust the Z axis acceleration in mm/ second/second. This can be
kept high or low as per the lifter design.
10. Slow IHS at
The system supports dual speed IHS. This helps prevent damage to the torch by hitting the
plate at the full speed of the Z axis. This settings lets you adjust the distance at which the slow
HIS is started. The THC assumes the last IHS location to be the 0 point. For example: if this
setting is set to 15mm and the slow IHS speed is set to 50% the torch would slow down at
15mm to 50% of the set speed.
11. Slow IHS Speed
This is the speed in percentage of the main THC speed that the THC would slow down to
during performing the IHS operation in dual speed.
12. Enable Ohmic HIS
This settings is used to ENABLE / DISABLE the ohmic based IHS.
13. Partial Raise Ht
This is the distance in mm that the torch is raised after each cut is over. This helps to avoid the
torch hit the cut parts during traversing to the next cut location.
14. Full Retract Dly
This is the time in seconds that the torch would be retracted fully till the up limit is triggered if no
activity is performed (Idle).
