NT Engineers DigiCut PLASMA THC 1.4 User Manual

PLASMA THC 1.4
INSTALLATION & OPERATION MANUAL
5 | P a g e w w w . n t e n g i n e e r s . i n
Specifications
Compatible Motors
Stepper or AC/DC Servo based on position mode of operation
(Step & Direction Signal)
Operating Voltage
Main THC:
24V DC
±5%
Voltage Divider: 240V AC ±5%
Ohmic IHS: 240V AC ±5%
Standard lifter range:
Based on lifter design
Motor output:
STEP & DIRECTION PNP
+5V SIGNAL and GND Outputs
MAX OUTPUT RESOLUTION
0.01mm
ACCURACY
±1 Volt
Voltage control range
45 to 220 VDC
Pierce Height
1.5 to 9.9 mm (User Adjustable)
Operator switches:
UP / Down
Auto / Manual
IHS Auto / Manual
HIS Test / Arc Test
Pierce Delay
Pierce Height
Cut Height
Settings
LED Status Indication:
POWER
CUT
PLASMA
MOTION
UP / DOWN
AUTO / MANUAL
IHS AUTO / MANUAL
Operating environment:
0 to 50C;
95% relative humidity (non-condensing)

NT Engineers DigiCut PLASMA THC 1.4 Specifications

General

Brand	NT Engineers
Model	DigiCut PLASMA THC 1.4
Category	Controller
Language	English
