15. Correction Speed
This is the maximum correction speed in mm/second that the THC will allow corrections to
happed during the Automatic Mode of operation. This speed is only affected during the actual
cutting operation.
16. Correction Acceleration
This is the correction acceleration setting in mm/second/second that will be effected during the
actual cutting operation.
17. Z Pulses per mm
This is setting of the Z axis resolution in terms of pulses per mm. For example: If the lifter has a
ball screw with a pitch of 5mm and the stepper driver is set to 200 pulses per rotation this
setting would be 200/5=40 pulses per mm.
18. Voltage Divider Ratio
This is the setting of the voltage divider ratio of the VOLTAGE DIVIDER CARD that is supplied
to you. Please confirm that value of this setting as per the card supplied to you from the
supplier.
19. Dynamic Pierce Ht Adj
When this setting is enabled and the user is adjusting and testing the pierce height by pressing
the HIS button, the THC would make rapid and immediate changes in height if the Pierce
Height POT is turned within 5 seconds of pressing the IHS button. This enables the user to
dynamically see the height adjustment without needing to do IHS again and again.
20. Cut Speed Siml
This option is implemented for our Service Personnel only and is not to be used by the user.
21. Move Fixed Dist
This option is implemented for our Service Personnel only and is not to be used by the user.
22. ArcOk Relay Tst
This is used to check and confirm the wiring of the Ok to Move (Motion) signal that is output to
the CNC from the THC by pressing the Up / Down buttons. This is only for diagnosis and initial
