5
Part 1 Propane Conversion Procedure
2. Perform preliminary adjustment on
gas valve throttle screw 4.
a. 085, 110, and 110C: Adjust throttle
screw 4 - counter-clockwise 0.5 turns.
b. 150, 199, 150C, and 199C: Adjust
throttle screw 4 - counter-clockwise 2
turns.
c. Turn the gas supply on and test for gas
leaks in all piping.
d. Perform gas line pressure test and
combustion calibration in accordance
with Parts 2 and 3.
NOTICE: 199 and 199C Models ONLY:
ADJUST HIGH AND LOW FAN SPEEDS
WHEN CONVERTED TO LP, THE 199 AND
199C MODELS MUST HAVE THE HIGH
AND LOW FAN SPEEDS ADJUSTED FROM
THE NATURAL GAS DEFAULT VALUES.
ACCESS THE TECHNICAL MENU AND
ADJUST PARAMETERS 232, 233, AND
234 IN ACCORDANCE WITH TABLE 4 -
MINIMUM AND MAXIMUM GAS FLOW,
IN THIS DOCUMENT.
i. Reassemble the gas pipe to the gas
valve and mixer.
ATTENTION!! USE THE NEW
RUBBER GASKETS PROVIDED
WITH THE KIT.
j. Install the silencer.
4
2
1
Figure 5 - Gas valve
