Features:
USB 2.0 Full Speed compliant and 1.1 supported, 8-96kHz/16-24-bit
S/PDIF input: Coaxial up to 192kHz/24-bit or Optical up to 96kHz/24-bit
Analog input: 3.5mm or RCA input
Audiophile-grade DA converter
Low-distortion, high-current headphone amplifier
High quality analog volume control
Specifications:
Analog Inputs: RCA or 3.5mm when inserted
Digital input: S/PDIF, Coaxial or 3.5mm when inserted
USB DAC: USB 1.0 and 1.1 up to 44.1kHz/16-bit, USB 2.0 Full-Speed up to 96kHz/24-bit
RCA Output: 2.6Vrms (cuts off when headphone is inserted)
Headphone Output: 6.3mm headphone output jack drives headphones up to 600-Ohm (96 mW@600-Ohm)
THD+N: 0.001%
Dynamic Range, SNR > 100dB
Power Requirement: 15V, 1.6A, 100-240VAC
Dimension: 6" x 4 1/2" x 1"
Weight: 1lb.
