Bypass (Input 5) - Power-off Bypass: input 5 is directly routed to the outputs whenever the P-9 is in the
off position. This facilitates integration with another device with its own volume control, such as a home-
theater processor.
Pre Out, RCA - Volume-controlled line-level outputs.
Balanced Outputs - Balanced XLR output interconnects for use with amplifiers having balanced inputs.
For bi-amp applications, both outputs (RCA and XLR) can be used simultaneously.
DIM - This feature is turned off as Factory default. To enable/disable DIM, press 'On' then '1'. Display
will show 'DIM=ON' when enabled, 'DIM=OFF' when disabled. When DIM=ON, display’s backlight will
be turned off when there is no activity after 10 seconds. Any activities (adj. volume, input, etc) will turn-
on the backlight display. However, turning the analog volume pot can not turn on the display’s backlight.
Remote Control:
The P-9 includes a simple remote control with the following functions:
Off - Turns off the P-9 while retaining the input and volume settings.
On - Turns the P-9 On.
Input Selection - Each push of the button will switch the P-9 to the next input.
Mute - Mutes volume. Turn or push any knob to un-mute.
Up - Volume increases.
Down - Volume decreases.
1, 2, 3, 4, 5 - Direct input access.
Note: A universal remote can be programmed to operate the P-9.
