BOM: C3 sub PCB
6.8K R6B 2 R771, R772
68K R6A 2 R671, R672
6mm JP6B 21 W01, W05, W07, W08, W09, W17,
W18, W21, W22, W23, W24, W26,
W27, W30, W31, W33, W35, W36,
W37, W38, W39
7.5MM JP7.5B 11 W03, W04, W10, W11, W12, W13,
W19, W20, W25, W28, W32
74HCT14 ICDIP14 2 IC803, IC804
78L05 TO-92 1 IC801
A
2543WV2-3P(BLU) M5045-03A 1 CN17
A
2543WV2-3P(RED) M5045-03A 1 CN18
A
2543WV2-4P M5045-04A 1 CN19
B5131J LED 1 LD921
CPJ-065 CPJ-065B 3 J602, J603, J651
E-PCB-214 PCB 1 PCB
E-VR-062-00 100KB*2 RS30 1 VR651
LB1403N ICSIP9 4 IC903, IC904, IC905, IC906
NJM4556AL ICSIP8 1 IC653
NJM4558L ICSEP8 1 IC651
NJM4558L ICSIP8 2 IC602, IC603
NJM4558M DMP-8 2 IC652, IC802
P-FR-050-00 LEDASSY-2 2 HLD9, HLD10
P-XT-060 LED-HLD 1 HLD11
RD16K1240060 10KB*2 RK16K12 1 VR652
RD16K124A061 50KB*2 RK16K12 1 VR703
RD16K12D0065 50KB*2 RK16K12 1 VR704
RS45Y12A2019 50KA*2 RS45LA 1 VR702
SLB-0285PO-030(GRN) R-LED 12 LD901, LD902, LD903, LD904,
