DM1200/DM1235/DM1285
SPECIFICATIONS...
INPUTS:
Line:10kΩ input impedance
80 mV rms sensitivity (for 1.22 V output)
Mic: 10kΩ input impedance balanced/unbalanced
2.5 mV rms sensitivity (for 1.22 V output)
500 mV rms max input
Phono: 47kΩ input impedance
1.5 mV rms sensitivity @ 1 KHz (for 1.22 V output)
OUTPUTS:
Line: 9V rms max (+20 dBm)
470Ω balanced. 3.5Vrms
100Ω balanced 1.12Vrms
Headphone Amp: .5 watt into 47Ω
Distortion less than .01%
EQUALIZER:
6-Band Stereo Graphic EQ
Band centers 42 Hz, 152 Hz, 480Hz, 1.52KHz, 4.8KHz,
15.36KHz +/- 15 dB
SIGNAL TO NOISE RATIOS (vs. maximum
output):
Line: Better than 85 dB
Mic: Better than 72 dB
Phono: Better than 83 dB
FREQUENCY RESPONSE:
Mic: 20 Hz- 15k Hz +_ .5 dB
Line: 20 Hz- 20k Hz +_ .5 dB
Phono: +_ 1 dB except for controlled attenuation
of -3 dB
@ 20 Hz to Reduce rumble and feedback
TALKOVER ATTENUATION:
variable from no cut to -16 dB
POWER CONSUMPTION:
20 Watt typical, 28 watt with full headphone output
DIMENSIONS: 482mmx232mmx111mm
19” x9 1/8” x4 3/8”
WEIGHT: DM1200 4.3kgs 9.6lbs
DM1235/DM1285 5.1kgs 11.2lbs
DM1235 with BEATKEEPER
Sync Lock Mode
BPM update rate Every beat
BPM accuracy +/- 1 BPM
BPM tracking range 50-199BPM
Bar graph update rate Every beat
Tempo difference graph resolution
+/-1 BPM per LED, Green is +/-2 BPM
Beat offset graph resolution
+/-7.5msec per LED, Green is +/-15msec
Beat Assist Button
Minimum time between consecutive taps
0.3 seconds
Maximum time between consecutive taps
1.2 seconds
Consecutive taps averaging for BPM
Last 2 to 8 taps
DM1285 with SAMPLER:
FREQUENCY RESPONSE AND SAMPLING RATE:
Variable sampling rate 44.1 kHz with 16-bit sampling
yields 20Hz-22 kHz.
MAXIMUM MEMORY TIME:
12 seconds
Numark - The Leader in DJ Technology
©1998 Industries 18 http://www.numark.com
