...3 MT1105534 AXIS CAP 2
0.1 PT1110771 Wheel Frame 2 4
0.1 PT113024401 Cabinet Printing 1 8
..2 PT1130244 Cabinet 1
0.1 PT1130366 Bottom Chassis 1 17
0.1 RU11106101 Rubber Button 15 12
0.1 RU1130728 Rubber Pad 4 18
0.1 SC0308RBNI SCREW M3X8 PRN TAPPING 7 26
0.1 SC0310RBBI Screw M3X10 PPB Tapping 10 24
0.1 WS1306505 Washer FLAT 13*6.5*0.5MM 2 6
0.1 WS186076005P Washer 6 28
0.1 TWCA050010001 Lightning Cable Assembly 1
..2 JKMFI677-0637-3 Lightning Connector MFI C10A-3 1
0.1 TWCA300010001 IPAD Cable Assembly 1
..2 JK512S0017-1 IPAD Connector 1
0.1 TWPC12C07001 Control PCB Assembly 1 25
..2 AA822519X IC LP2985IM5-3.3 1
U7
..2 AL2-50-4149 Diode Single 1N4148 100V 200mA 4
D6~9
..2 AL2-51-4401 TRANSISTOR 2N4401 NPN 10
Q1~5,8,16~19
..2 AL2-51-4403 TRANSISTOR 2N4403 PNP 4
Q6,7,20,21
..2 AL2-54-6306 Mosfet FDC6306P P-CH SSOT-6 2
Q48,U4
..2 CS102J5003NPO CCAP SMD 1nF/50V 5% 0603 NPO 8
C10~17
..2 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 3
C4,5,22
..2 CS103K5005X7R CCAP SMD 0.01uF/50V 10% 0805 X7R 1
C47
..2 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 22
C1~3,6~9,18,19,24,27,28,30~32,35,37,38,
..2 CS104K5005X7R CCAP SMD 0.1uF/50V 10% 0805 X7R 2
C50,119
..2 CS105K1003X5R CCAP SMD 1uF/10V 10% 0603 X5R 1
C115
..2 CS180J5003NPO CCAP SMD 18pF/50V 5% 0603 NPO 2
C25,29
..2 CS470J5003NPO CCAP SMD 47pF/50V 5% 0603 NPO 2
C26,39
..2 CS475K1606X7R CCAP SMD 4.7uF/16V 10% 1206 X7R 4
C21,33,36,41
..2 DIRPI-352 SENSOR 4
SEN1~4
..2 IC2-77-0103 Touch IC (2-77-0103) 1
U2
..2 ICMFI341S2162-1 IC MFI341S2162-1 1
U6
..2 ICSN74HC14D IC SN74HC14D 1
U3
..2 ICUSBLC62SC6 IC USBLC62SC6 1
U15
..2 ICYH102C01 IC YH102C01(STM32F102R8T6+Program) 1
U1
...3 ICSTM32F102R8T6 IC STM32F102R8T6 1
-
..2 ICYHFRC232 IC YHFRC232 (PIC10F204I+PROGRAM) 1
U5
...3 ICPIC10F204I IC PIC10F204-I/OT SOT-23 1
-
..2 LDKPHK-1608CGCK LED GREEN SMD 0603 2
D12,13
..2 LDKPHK-1608SYCK LED YELLOW SMD 0603 1
D1
..2 LDKPT-1608SURCK Liquid-emitting Diode Red SMD 2
D10,11
..2 MT070446701 IRON PLATE 1
(ENC1)
..2 PC12C070 Control PCB 1
-
..2 RS000110J03 RESISTOR 1Ω 5% SMD 0603 1
R22
..2 RS001K10F03 RESISTOR 1K 1% SMD 0603 5
R20,60,62,66,68
..2 RS001M10F03 RESISTOR 1M 1% SMD 0603 3
R34,38,160
..2 RS002210F03 RESISTOR 22Ω 1% SMD 0603 2
R32,35
..2 RS005610F03 RESISTOR 56Ω 1% SMD 0603 2
R64,65
..2 RS008210F03 RESISTOR 82Ω 1% SMD 0603 3
R16,58,59
..2 RS010K10F03 RESISTOR 10K 1% SMD 0603 16
R1~4,11,12,23,24,27,29~31,40~42,55
..2 RS01K510F03 RESISTOR 1.5K 1% SMD 0603 1
R37
..2 RS020K10F03 RESISTOR 20K 1% SMD 0603 1
R51
..2 RS022010F03 RESISTOR 220Ω 1% SMD 0603 1
R33
..2 RS022K10F03 RESISTOR 22K 1% SMD 0603 4
R9,10,18,19
