Numark IDJ LIVE II Service Manual

..2 RS033010F03 RESISTOR 330Ω 1% SMD 0603 4
R7,8,15,17
..2 RS056010F03 RESISTOR 560Ω 1% SMD 0603 4
R5,6,13,14
..2 RS05K110F03 RESISTOR 5.1K 1% SMD 0603 1
R48
..2 RS068K10F03 RESISTOR 68K 1% SMD 0603 2
R26,28
..2 RS100K10F03 RESISTOR 100K 1% SMD 0603 8
R25,36,39,46,47,49,50,52
..2 SWDC11B2021431 Switch Rotational Encode 20Pul 1
ENC1
..2 TCS106K160B Solid Tantalum Electrolytic 2
C48,49
..2 TE622000501 5P CONNECTOR 1
(J1)
..2 TE962542001 Terminal 20P 2.54mm 1
(J2)
..2 TR2SK1828 MOSFET N-CH 20V MAIN 2-Pin 4
Q10~13
..2 VRR10301701 VARIABLE 10KB 3
P1~3
..2 VRR10301704 Poltertiomaeter Rotary Volume 4
P4~7
..2 VRS10304531 Potentiometer Slide 10k 0B 45m 1
P9
..2 XTM08000X6F1 Crystal 8MHZ 49US SMD Fundamen 1
X1
