20. Sync-----------------------This control sends a momentary MIDI message. This control is used to force the track to align
with the other deck’s tempo and phase. It is up to the software to either hard align or gently
nudge it into place, depending on the Smart or Simple Sync chosen from the settings. The LED
for this control will light when active.
21. Cue Gain------------------adjusts volume of headphone pot.
22. Cue Mix-------------------Selects Master or PFL outputs in the headphones.
23. Loop On/Off--------------Loop On/Off (Tact Switch w/ Amber LEDs) When pressed, activates autoloop on/off. Loop size i
is determined by what is set in the software.
24. ½ Loop--------------------When a loop is active this will decrease the loop size by ½.
When inactive changes the default trigger size.
25.
2x Loop-------------------When a loop is active this will double the loop size.
When off changes the default trigger size.
26.
Shift------------------------this button will add/perform secondary functions when another button is pressed while still
holding.
This control will adjust the Input volume of the Microphone.
The Microphone GAIN is summed with the master output of the software.
AUDIO OUTPUT
LINE OUT
OUTPUT LEVEL-------------1.3±0.2Vms(1KHz 0dB)
S/N RATIO---------------------MORE THAN 80dB
CHANNEL SEPARATION--MORE THAN 80dB
HARMONIC DISTORTION-LESS THAN 0.03%
HEADPHONE OUT(Load:32
Ω
)
OUTPUT LEVEL--------------0.65±0.1Vms(1KHz 0dB)
S/N RATIO--------------------- MORE THAN 80dB
HARMONIC DISTORTION-LESS THAN 0.03%
MIC INPUT(Load:32)
OUTPUT LEVEL--------------1.4±0.2 Vms (1KHz 0dB)
