SPECIFICATION
FUNCTION
1. UI Browser----------------A standard detented encoder with push switch is used to navigate through the software
2. Master Volume-----------Controls the gain of the master outputs.
3. Gain------------------------This pot controls the gain for its associated channel on the mixer.
4. Treble----------------------This knob controls the high end treble output of its associated channel on the mixer.
5. Mid-------------------------This knob controls the Mid-range frequency of its associated channel on the mixer.
6. Bass------------------------This knob controls the low end bass frequencies of its associated channel on the mixer.
7. Filter-----------------------This center detented knob acts as a low pass filter from center sweeping left and a high pass filter
from center sweeping right.
8. Channel Fader------------This is the volume controller for the channel. Channel faders are not user replaceable.
9. Cross Fader---------------This fader is for transitioning from Left assigned (A) Cross fader Deck Position to Right
assigned (B) Cross fader Position.
10. Channel PFL------------This button activates the Headphone CUE for its associated channel allowing users to preview
tracks in the Headphone CUE.
11. Software FX-------------These radio style buttons will allow the end-user to have instant access to choose a single
software effect.
12. FX Paddle On/Off------This is used to activate software FX for the corresponding deck.
13. Software FX Wet/Dry--This knob Adjusts the Wet/Dry of all FX.
14. Beats Multiplier Knob--This pot determines the Time division associated with the selected effect.
15. Tap------------------------This allows the end-user the ability to manually tap in the tempo of the software effects
engine. SHIFT + returns the tempo to the tracks default BPM.
16. DECK Selector----------This switch will select deck control and focus between decks 1 & 3 on the Left side and 2 & 4 on
the right side.
17. Platter/Jog----------------This control sends Relative MIDI data when turned, and when the jog is touched sends a separate
momentary MIDI message.
18. Pitch Fader----------------This control sends absolute MIDI data.
19. Pitch Bend “-”------------This momentary button will temporarily increase the play back speed of the track allowing the
user to better align their mix.
Pitch Bend “+”-----------This momentary button will temporarily increase the play back speed of the track allowing the
user to better align their mix.
MODEL: MIXTRACKPROFX
