Numark MIXTRACK3 Service Manual

...3 CS470J5005NPO CCAP SMD 47pF/50V 5% 0805 NPO 1 C514
...3 CS473K5005X7R CCAP SMD 0.047uF/50V 10% 0805 1 C503
...3 DICM1213A01SO Diode ESD Protection Arrays CM 2 D500,501
...3 DIEN1N4148WSM Diode SMD 2 D502,503
...3 DIPH574 Photo Sensor 2 SEN500,501
...3 FCN1T1000401 FCN Up Touch ZIF SMD Pitch=1.0mm 1 FCN500
...3 FCN1T1003201 FCN Down Touch ZIF Pitch:1.0mm 1 FCN501
...3 IC74HC4051PW IC 74HC4051PW SINGLE 8-CHAN MUX 1 IC501
...3 ICSN74LVC3G14 IC SN74LVC3G14 1 IC500
...3 JW5206T Jumping Wire 23 JW501~523
...3 LD3R4ST702-1 Liquid-emitting Diode Red Asti 21 LED500~520
...3 MT0701840 EARTHER METAL 1 (MT500)
...3 RS000008J05 RESISTOR 0Ω 5% SMD 0805 16 R535,RR501~515
...3 RS001K08F05 RESISTOR 1K 1% SMD 0805 7 R500,514~519
...3 RS001M08F05 RESISTOR 1M 1% SMD 0805 1 R546
...3 RS007508F05 RESISTOR 75Ω 1% SMD 0805 2 R542,543
...3 RS010008F05 RESISTOR 100Ω 1% SMD 0805 2 R533,534
...3 RS010K08F05 RESISTOR 10K 1% SMD 0805 14 R503~513,537,539,540
...3 RS015K08F05 RESISTOR 15K 1% SMD 0805 2 R544,545
...3 RS039008F05 RESISTOR 390Ω 1% SMD 0805 1 R501
...3 RS047K08F05 RESISTOR 47K 1% SMD 0805 1 R502
...3 RS056008F05 RESISTOR 560Ω 1% SMD 0805 2 R538,541
...3 RS068K08F05 RESISTOR 68K 1% SMD 0805 1 R532
...3 RS075008F05 RES ISTOR750Ω 1% SMD 0805 15 R520~531,547~549
...3 RS100K08F05 RESISTOR 100K 1% SMD 0805 1 R536
...3 SWDC11B2020469 Switch Rotational Encode 20Pul 1 ENC500
...3 SWEVQ11L05R Switch Tact 5mm 160g Horizonta 9 SW500~508
...3 TR2SC2412KSM TRANSISTOR 2SC2412KSM 2 Q504,505
...3 TR2SK1828 Mosfet N-CH 20V MAIN 2-Pin 2 Q502,503
...3 VRS10310013 Potentiometer Rotary Valume 10 1 VR500
..2 TWPC14C031D02 MIC PCB Assembly 1 25
0.1 TWPC14C03201 PAD PCB Assembly 1
..2 PC14C032 PAD PCB 1
..2 TWPC14C032A01 Left PAD PCB Assembly 1 42
...3 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 2 C701,702
...3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 2 C703,704
...3 CS561J5003NPO CCAP SMD 560pF/50V 5% 0603 NPO 2 C705,706
...3 DIEN1N4148WSM Diode SMD 11 D700~710
...3 FCN1T1002201 FCN Down Touch 90° Pitch=1.0mm 1 FCN700
...3 IC74HCT595D IC 74HCT595D 2 IC700,701
...3 LDKPT-1608SURCK Liquid-emitting Diode Red SMD 8 LED700~703,714~717
...3 LDLTST-C190KSKT Liquid-emitting Diode Amber SMD 4 LED707,709,711,713
...3 LDLTST-C193TBKT Liquid-emitting Diode Blue SMD 4 LED706,708,710,712
...3 LDLTST-C193TGKT Liquid-emitting Diode Green SMD 2 LED704,705
...3 RS001K10F03 RESISTOR 1K 1% SMD 0603 6 R714~719
...3 RS003310F03 RESISTOR 33Ω 1% SMD 0603 6 R707~712
...3 RS010K10F03 RESISTOR 10K 1% SMD 0603 2 R700,701
...3 RS022010F03 RESISTOR 220Ω 1% SMD 0603 8 R720~727
...3 RS047010F03 RESISTOR 470Ω 1% SMD 0603 4 R728~731
...3 SWEVQ11L05R Switch Tact 5mm 160g Horizonta 3 SW708~710
..2 TWPC14C032B01 Right PAD PCB Assembly 1 45
...3 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 2 C801,802
...3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 2 C803,804
...3 CS561J5003NPO CCAP SMD 560pF/50V 5% 0603 NPO 1 C805
...3 DIEN1N4148WSM Diode SMD 11 D800~810
...3 FCN1T1002201 FCN Down Touch 90° Pitch=1.0mm 1 FCN800
...3 IC74HCT595D IC 74HCT595D 2 IC800,801
...3 LDKPT-1608SURCK Liquid-emitting Diode Red SMD 8 LED800~803,814~817
...3 LDLTST-C190KSKT Liquid-emitting Diode Amber SMD 4 LED807,809,811,813
...3 LDLTST-C193TBKT Liquid-emitting Diode Blue SMD 4 LED806,808,810,812
...3 LDLTST-C193TGKT Liquid-emitting Diode Green SMD 2 LED804,805
