Numark NS6 Service Manual

..2 PT1110734 Wheel Frame 2
0.1 PT1130209 TOP HOUSING 1 50
0.1 PU008008001 Pu Foam 2 91
0.1 PU010010010 QUARANTINE CLOTH 3 84
0.1 PU014006006 Qurantine Cloth 1 101
0.1 RN109111 FIXED RING 2 52
0.1 RU0730605 RUBBER FOOT 6 65
0.1 SC0305FA2IBI Screw M3X5 HFB 4 75
0.1 SC0305PIBI SCREW M3X5 PPB 7 80
0.1 SC0308ABBI Screw(FLAT) 34 74
0.1 SC0308ABNI Screw 21 79
0.1 SC0308AINI Screw 8 78
0.1 SC0308FIBNI Screw M3*8 PFB W/NYLOC 4 97
0.1 SC0308RBNI SCREW M3X8 PRN TAPPING 50 77
0.1 SC0314PMJI Screw M3X14 PPN 1 92
0.1 SC2605RBNI SCREW M2.6X5 PPN TAPPING 14 76
0.1 TSNK18 CD 1
0.1 TWNP632YAH10601 Douser Assembly 2
..2 MT321004001 DOUSER PLATE FIXED BASE 2 73-1
..2 MT3210070 PLATE 4 73-3
..2 NP632YAH106 DOUSER 2 73-4
..2 RN0416001 CS RING 2 73-5
..2 SC0303SIBI SCREW M3X3 HXB 2 73-2
0.1 WR0620001001 Isolation Cable 6Pin Single Row Pitch 2.0mm Length 1
0
185
0.1 WR0620003001 Isolation Cable 6Pin Single Row Pitch 2.0mm Length 3
0
190
0.1 WS073307IC Washer Flat 3 93
0.1 WS113008204IB Washer 2 43
0.1 WS663309IC Spring Washer 3# 1 95
0.1 AL9-79-0573 AN PCB ASS'Y 1
..2 AL9-40-0573 AN PCB 1
..2 AL9-79-0573A01 AN PCB ASS'Y 1 62
...3 AA822757X TRANSISTOR 2SC3326 NPN 12 Q1~8,13~16
...3 AL0-17-0103 RESISTOR ARRAY 4X10K 1/10W 0603 3 R41,42,219
...3 AL0-17-0470 RESISTOR ARRAY 4X47 1/10W 0603 6 R181,192,209,212,225,226
...3 AL1-08-0474 Capacitor Electrolytic 47uF/16V 5*11mm 1 C208
...3 AL2-50-4149 Diode Single 1N4148 100V 200mA SOT-23 2 D4,7
...3 AL2-51-0340 DIODE POWER SCHOTTKY MBRA340T3 40V 3A SM 7 D2,5,6,8,12,16,17
...3 AL2-51-4401 TRANSISTOR 2N4401 NPN 2 Q10,19
...3 AL2-51-4403 TRANSISTOR 2N4403 PNP 3 Q9,11,17
...3 AL2-54-6306 Mosfet FDC6306P P-CH SSOT-6 1 Q18
...3 AL2-61-0431 REG LM431 2.5V-37V 100MA 2% SOT-23 1 U32
...3 AL2-61-5000 IC REG VOLTAGE NCP500SN25T1 2.5V SOT23-5 1 U30
...3 AL2-63-0126 IC SINGLE BUS BUFFER GATE WITH SN74AHCT1G1 1 U27
...3 AL2-71-3079 IC MC33079 QUAD OP-AMP SOP-14 3 U3,6,11
...3 AL2-74-0181 IC OPTO-ISOLATOR TLP181 TRANS-OUT SMD 1 SEN1
...3 AL4-02-0007
JACK 1/4 STEREO 7-PIN FEM MINI W/GRND LUG STRAI
G
2 J1,5
...3 AL4-08-0402 Con USB 4-Pin Female PC-MNT Horizontal 1 J11
...3 AL7-01-0046 Crystal 12MHZ 49US SMD Fundamental 1 X1
...3 AL7-20-0067 INDUCTOR 33uH 1.8A SMD 1 L7
...3 AL7-20-0087 Inductor 15uH 2.3A ±15% 10.5×9.0mm DIP 1 L4
...3 CS101J5003NPO CERAMIC 100pF/50V 5% 0603 NPO 32
C4~16,18,19,23,30,31,34,35,57,60,64,73,91,100,106,1
10,154,159,163,167
...3 CS102J5003NPO CERAMIC 1nF/50V 5% 0603 NPO 6 C63,74,105,111,162,168
...3 CS103K2502X7R CERAMIC 0.01UF/25V 10% 0402 X7R 14 C3,92,95,148,160,175,204~206,209,210,219,221,225
...3 CS104K2502X5R CERAMIC 0.1UF/25V 10% 0402 X5R 90
C1,2,20,29,38,39,45~52,54,62,67,72,75~77,84,86,88,9
3,94,96~98,102,103,109,113,115,116,118,120,121,125
~129,131,132,134,136,139,140,142,144,145,147,149~
151,156,157,161,166,170,176,177,184~188,192,193,1
95,196,199,200,203,207,211~216,220,222,226,227,23
1,236~238
...3 CS104K5003X7R CERAMIC 0.1uF/50V 10% 0603 X7R 12 C40,41,79,124,158,164,172,178,189,R188,252,257
...3 CS105K1003X5R CERAMIC 1uF/10V 10% 0603 X5R 12 C21,114,117,141,155,183,194,218,223,228,229,230
...3 CS152J5003NPO CERAMIC 1500PF/50V 5% 0603 NPO 4 C42,43,55,56
...3 CS180J5003NPO CERAMIC 18pF/50V 5% 0603 NPO 6 C22,69,101,119,122,123

Numark NS6 Specifications

General

Sample rate	441 kHz
Channels quantity	4 channels
Digital sound processing	24 bit
MIDI out	Yes
Booth out (1/4\")	1
Dimensions (WxDxH)	603 x 340 x 64 mm

Weight and Dimensions

Weight	6330 g
