Numark NS6 Service Manual

...3 CS221J5003NPO CERAMIC 220pF/50V 5% 0603 NPO 4 C28,37,44,53
...3 CS272J5003NPO CERAMIC 2.7nF/50V 5% 0603 NPO 8 C179~182,224,232~234
...3 CS471J5003NPO CERAMIC 470pF/50V 5% 0603 NPO 8 C107,112,130,135,137,138,197,201
...3 CS472J5005NPO CERAMIC 4.7nF/50V 5% 0805 NPO 4 C32,33,58,59
...3 DISDBAT54SSM Diode BAT54S 30V 0.2A SOT-23 8 D9~11,13~15,21,22
...3 EC10625TS Capacitor Electrolytic 10uF/25V 5*5mm 1 C87
...3 EC10725T Capacitor Electrolytic 100uF/25V 6.3*11mm 1 C61
...3 EC22616TS Capacitor Electrolytic 22uF/16V 5*5mm 7 C82,143,171,190,198,217,235
...3 EC22716TS Capacitor Electrolytic 220uF/16V 8*5mm 1 C202
...3 EC22735TLE Capacitor Electrolytic low ESR 220u/35V 10*13mm 3 C83,99,146
...3 EC47525TLE Capacitor Electrolytic low ESR 4.7uF/25V 5*11mm 1 C68
...3 EC47635TLE Capacitor Electrolytic low ESR 47uF/35V 6.3*11mm 16 C17,24~27,36,70,71,89,90,104,108,152,153,169,174
...3 EC47725TLE Capactor Electolytic LOW-ESR 470UF/25V 5X10X13m
m
2 C133,191
...3 ECS68606DLE ECAP 68uF/6.3V 6.3X5.4mm SMD-D LOWESR 1 C78
...3 FCN1T1002602 FCN Down Touch ZIF SMD Pitch=1.0mm 26P 1 J25
...3 IC74AHC1G08GV IC74AHC1G08 SOT23-5 1 U14
...3 IC74AHC245PW IC SN74AHC245PWR 2 U15,20
...3 IC74AHCT245PW IC SN74AHCT245PWR 1 U8
...3 ICAP1501K5L IC AP1501K5L 1 U10
...3 ICAP1510SL-13 IC AP1510SL-13 1 U22
...3 ICBA033FP IC BA033FP 1 U21
...3 ICBF531 IC DSP ADSP-BF531 1 U17
...3 ICCS4385-CQZ IC CS4385-CQZ 1 U28
...3 ICCS5368 IC CS5368 1 U26
...3 ICISP1583BS IC ISP1583BS 1 U4
...3 ICLM393DR IC LM393DR 1 U31
...3 ICMC33078DR2G IC MC33078DR2G 7 U1,2,5,9,12,24,29
...3 ICMIC809SU IC MIC809SU 1 U16
...3 ICNJM-2114M IC NJM-2114M 2 U13,19
...3 ICUSBLC62SC6 IC USBLC62SC6 1 D1
...3 ICYHFRC163 IC YHFRC163 (AL2-80-0256+Program) 1 U18
....4 AL2-80-0256 IC LCMX0256 1 -
...3 ICYHFRC164 IC YHFRC164 (ICATMEGA162+Program) 1 U7
....4 ICATMEGA162 IC ATMEGA162 1 -
...3 JKDJ-0702B-020 DC BASE 2.0MM 1 J12
...3 RJ1039-09-0580B RCA Jack(One Output) 6 J2~4,6~8
...3 RS000004J06 RESISTOR 0Ω 5% SMD 1206 1 R249
...3 RS000010J03 RESISTOR 0Ω 5% SMD 0603 25
R1,2,6,8,10~14,16,18,19,22,24,26,32,40,43,44,48,117
~120,258
...3 RS001K10F03 RESISTOR 1K 1% SMD 0603 17 R34~39,47,53,132,142~145,162,169,234,248
...3 RS001M10F03 RESISTOR 1M 1% SMD 0603 2 R3,30
...3 RS003303F10 RESISTOR 33Ω 1% SMD 1210 8 R153~156,176~179
...3 RS004710F03 RESISTOR 47Ω 1% SMD 0603 16
R49,55,94,101,106,110,114,148,151,199,216,217,229,
231~233
...3 RS010010F03 RESISTOR 100Ω 1% SMD 0603 4 R45,62,64,74
...3 RS010K10F03 RESISTOR 10K 1% SMD 0603 27
R46,63,65,75,89~92,99,100,104,105,109,111,157,164,
170,189,198,204,205,213,247,250,260,262,263
...3 RS012K10F03 RESISTOR 12K 1% SMD 0603 1 R50
...3 RS01K110F03 RESISTOR 1.1K 1% SMD 0603 8 R121,127,128,131,182,187,190,197
...3 RS01K310F03 RESISTOR 1.3K 1% SMD 0603 1 R194
...3 RS01K510F03 RESISTOR 1.5K 1% SMD 0603 1 R51
...3 RS01K610F03 RESISTOR 1.6K 1% SMD 0603 8 R83,85,86,88,95,98,102,103
...3 RS022108F05 RESISTOR 221Ω 1% SMD 0805 8 R4,5,27~29,33,52,54
...3 RS039K10F03 RESISTOR 39K 1% SMD 0603 4 R67,68,71,73
...3 RS043210F03 RESISTOR 432Ω 1% SMD 0603 11 R76,133,140,141,150,168,172,201,202,210,215
...3 RS047010F03 RESISTOR 470Ω 1% SMD 0603 1 R259
...3 RS04K710F03 RESISTOR 4.7K 1% SMD 0603 1 R261
...3 RS063410F03 RESISTOR 634Ω 1% SMD 0603 12 R56,61,77,82,135,138,158,161,166,174,220,223
...3 RS082510F03 RESISTOR 825Ω 1% SMD 0603 8 R134,139,149,152,167,173,214,218
...3 RS100K10F03 RESISTOR 100K 1% SMD 0603 12 R7,9,15,17,20,21,23,25,31,171,180,206
...3 RS14K310F03 RESISTOR 14.3K 1% SMD 0603 4 R84,87,96,97
...3 RS16K910F03 RESISTOR 16.9K 1% SMD 0603 1 R253
...3 RS2K9410F03 RESISTOR 2.94K 1% SMD 0603 1 R251
...3 RS3K0110F03 RESISTOR 3K01 1/10W SMD 1/10W 0603 1 R207

Numark NS6 Specifications

General

Sample rate	441 kHz
Channels quantity	4 channels
Digital sound processing	24 bit
MIDI out	Yes
Booth out (1/4\")	1
Dimensions (WxDxH)	603 x 340 x 64 mm

Weight and Dimensions

Weight	6330 g
