AC Inlet : Connect the supplied mains lead to the AC IN (115V or 230 V) terminal on the rear of the DAC.
Others :
AC Voltage Selector : Make sure that the AC voltage selector switch at the bottom of the unit is switched
to the appropriate voltage for your country. All NuPrime products are shipped with
the switch set to 230V AC in order to prevent accidental damage.
230
LEFT RIGHT GND
Headphone Pin define:
Standard 6.3mm stereo plugs
