Quick Start Guide
Front Panel View:
Back Panel View:
Inputs:
RCA: Un-Balanced input x 1
XLR: Balanced input x 1
Outputs:
Stereo Speaker Out x 1
or
Mono Speaker Out x 1
AC Inlet Voltage Selector:
Make sure that the AC voltage selector switch at the bottom of the unit is switched to the appropriate
voltage for your country. All STA-9s are shipped with the switch set to 230V AC in order to prevent accidental
damage.
Turn ON the AC power switch at the rear of the unit. The STA-9 will now be in standby mode. Blue LED
indicator lights up on the front panel.
Stereo Connection:
