Flashing of software / delete flash / cancel:
Depending on what you intend, one of the following 3 buttons should be pressed:
- Delete flash (4): If the complete flash memory should be deleted and prepared for the new
software, please press the button “delete flash”. This is necessary if the software has to be
installed for the first time on the basic board.
Do not delete the memory flash, if the current software should be updated.
- Standard flashing (9): If there exist already a software on the control board or if the flash
memory was earlier deleted through the "delete flash " button, then use the “Standard
flashing" button and the selected software afore will be flashed.
- Cancel (5): The current procedure (delete flash or standard flashing) can be cancelled
through this “cancel” button. Depending on the progress of the procedure, is it possible that
the software was already partly-implemented or not. If the blue progress bar you can still see
with the deletion of the flash memory in the left half and then if the "cancel" button is pressed,
the deletion of the flash memory will be cancelled. The deletion was not implemented at this
time yet. The software played afore is still available after the restart.
You can see the progress of the selected procedure at blue progress bar (11) down on the
screen. Depending on procedure, the progress goes faster or slower. After the start and before it
ends, the progress bar is a certain time available on a screen.
Right down in the white status field (10) will be shown a message, which describes the current
condition of the selected procedure. Here also error messages will be shown.
If a procedure was ended or cancelled, the reset button must be pressed on the control board
which is going to be flashed (e.g. S1 reset on the control board A1and/or S2 reset on the indicator
board A2 of the brake test stand) or the machine with the control board which is going to be
flashed must be switched off and on
g. End of the flashing procedure
The flashing procedure is completed, if the blue progress bar (11) disappears again, the buttons
are activated again and in the status field appears a message. The message gives information
whether the flashing procedure or deleting was successfully completed or not.
h. After flashing procedure:
• Switched off the machine
• The Jumper on the flashed board must be changed again. It can only be connected to one
contact/pin.
• The serial cable can be taken off again. The occupied during flashing procedure serial
interface, can be yet plug-in with the previous cable.
• For normal work with the new software the machine must be restarted.
