JUMBO NT 3500
Automotive lift date: 09/2013
Manual date: 30.09.2013
Operating Instruction and Documentation
Serial number:...........................................
Otto Nußbaum GmbH & Co.KG//Korker Straße 24//D-77694 Kehl-Bodersweier
Tel: +49(0)7853/8990 Fax: +49(0)7853/8787
E-mail: info@nussbaum-lifts.de//http://www.nussbaum-lifts.de
Retailer address / phone
Original Documentation
Made in German
y

Table of Contents

Questions and Answers

  • K
    Kimberly ThompsonAug 6, 2025
    What to do if my Nussbaum JUMBO NT 3500 Lifting Systems does not lift or lower?
    • K
      Kathy SotoAug 6, 2025
      If your Nussbaum Lifting System isn't lifting or lowering, start by checking the power supply, ensuring the main switch is on and functional. Then, inspect the operating elements and the fuse for any defects. Also, check the feed line for cuts. If the motor is overheated, allow it to cool down. If the motor is defective, perform an emergency lowering following the instructions in chapter 6.2.
  • N
    Norma SmithAug 16, 2025
    Why is my Nussbaum JUMBO NT 3500 motor running but not lifting?
    • S
      Shannon HendrixAug 16, 2025
      If the motor of your Nussbaum Lifting System runs but the load isn't lifting, first, ensure the vehicle isn't too heavy by unloading it. Then, check the oil level, ensuring it's approximately 2cm under the filler. Verify that the emergency lowering screws N1 & N2 are closed and inspect the hydraulic lines for jams. Also, check the hydraulic system and screw fittings for any leakage. If these steps don't resolve the issue, the hydraulic pump is defective, the coupling between pump and motor is defective, or the cylinder jams.
  • W
    wangshaneAug 26, 2025
    What to do if Nussbaum Lifting Systems won't lower?
    • K
      Kristin OlsenAug 26, 2025
      If your Nussbaum Lifting System won't lower, ensure the platform isn't obstructed by anything; if so, raise the lift to remove the obstacle. Check the fuse. Also, make sure the lowering button is pressed and functioning correctly. If these steps don't solve the problem, the hydraulic valve is defective.

Summary

Foreword

Obligations of the user

User must observe operating instructions and safety regulations.

Obligations of the operator

Operator must ensure trained personnel and understanding of safety symbols.

Dangers when operating the lift

Improper use can lead to injury or death.

Organisational Requirements

Instructions must be accessible; refresher courses and PPE are required.

Maintenance works, repairing faults

Guarantee and liability

Record of installation

Record of handing over

1. Introduction

1.1 Installation and check of the automotive lift

Only specialist staff can perform safety checks and installation.

1.2 Information of Warning

Explains warning symbols used in the manual (Danger, Caution, Attention).

2. Master document of the automotive lift

2.1 Lift-manufacturer

Details of the manufacturer, Otto Nußbaum GmbH & Co. KG.

2.2 Application

Specifies lift capacity, load distribution, and intended use for vehicles.

2.3 Changes at the construction

Procedure for documenting construction changes and expert checks.

2.4 Displacement of the automotive-lift

Procedure for documenting lift relocation and expert checks.

2.5 Attestation of conformity

3. Technical Information

3.1 Technical ratings

Lists capacity, dimensions, power, and hydraulic specifications.

3.2 Safety device

Details the various safety mechanisms incorporated in the lift.

3.3 Datasheet

3.4 Foundation plan

3.5 Dowel Positions

3.6 Hydraulic diagram drawing

3.7 Connection of the hydraulic tubes

3.8 Electrical diagram drawing

Bill of materials

4. Safety regulations

5. Operating instructions

5.1 Lifting the vehicle

Step-by-step guide on how to safely lift a vehicle.

5.2 Lowering the vehicle

5.3 Equalization the platforms

6. Troubleshooting

Problem: The automotive does not lifting and lowering!

Solutions for issues related to the lift not moving up or down.

Problem: Motor läuft an, Last wird nicht gehoben!

Solutions when the motor runs but the load isn't lifted.

Problem: Hebebühne lässt sich nicht absenken!

6.1 Driving on an obstacle

6.2 Emergency lowering

7. Inspection and Maintenance

7.1 Inspection and Maintenance

Procedures for routine inspections and preventive maintenance.

Check the torque moments of the screws and dowels

7.2 Cleaning of the automotive lift

8. Security check

9. Installation and Initiation

9.1 Installation of the automotive lift

Options for positioning the operating unit during installation.

9.2 Regulations for the installation

Key regulations and requirements for installing the lift.

9.3 Erection and doweling of the lift

Procedures for erecting the lift and securing it with dowels.

9.4 Filling and bleeding the hydraulic system

9.5 Initiation

9.6 Changing the installation place

Dowel Length Selection (No Floor Pavement)

Dowel Length Selection (With Floor Pavement)

First security check before installation

Regular security check and maintenance

Extraordinary security check

Nussbaum JUMBO NT 3500 Specifications

General IconGeneral
BrandNussbaum
ModelJUMBO NT 3500
CategoryLifting Systems
LanguageEnglish
