2
ROOF CAP
ROOF CAP
REMOVE THE
HOOD DAMPER
FLAP IF IT IN-
TERFERES WITH
THE WALL CAP
DAMPER
outside wall. If a wall cap is used directly off the back of the
hood, special care must be taken to make sure that the damper
in the damper/duct connector on the hood and damper in the
wall cap do not interfere with each other when the hood is
operating. This could result in either inadequate air delivery
duct vertically and then use an elbow.
duct. For single story installations.
Ducting between ceiling joists for multi-story installations or
walls.
pRepARING THe
INsTAllATION lOCATION
NOTE: MOUNT HOOD SO THAT BOTTOM OF HOOD IS 18"
TO 25" ABOVE COOKING SURFACE. TOP FRONT OF HOOD
SHOULD BE FLUSH WITH FRONT OF CABINET FRAME.
IF DISTANCE BETWEEN WALL AND FRONT OF CABINET
FRAME IS MORE THAN 12", THERE WILL BE A SPACE BE-
TWEEN BACK OF HOOD AND WALL. THIS IS NORMAL.
OMIT STEP 1 IF HOOD WILL BE INSTALLED UNDER CABI-
NETS WITH FLUSH BOTTOM.
strips on each side of recessed area under cabinet. Use two
Fasten strips with wood screws about 3" in from each end.
only
FILLER STRIP
DAMPER
-
LEAST 6" FROM HOOD
IN VERTICAL SECTION
OF DUCT
LIGHT LENS
ALUMINUM OR
COMBINATION
FILTER
JUNCTION BOX
VENT COVER
pRepARING THe HOOd
1 – Filter with built-in light lens
1 – Installation parts bag
3. Remove top or rear electrical knockout.
Non-Vented — Remove vent cover from hood front. Replace
-
tion".
Rectangular Vented-
move knockout #➁ for vertical or knockout #➂ for horizontal
venting. Install damper/duct connector over opening. Go to
"Planning Ductwork Installation".
Round Vented — 7" vertical. Remove knockouts #➀ and #➁
plANNING dUCTWORk
INsTAllATION
This section for vented hoods only. Non-vented hoods skip
this section and go on to "Preparing the Installation Loca-
tion".
Begin planning ductwork by deciding where duct will run between
hood and outside. For best performance, use shortest possible
duct run and a minimum number of elbows. There are several
choices.
➀
➂
To Next Page
