EMPTYING THE DEBRIS PAIL (CONT’D)
CLEANING THE INTERNAL FILTER
When emptying the debris pail, it is a good idea to also clear
any dust and dirt that may have accumulated on the internal
filter media. To do this, simply open the direct door, reach in
and tap the top of the internal filter (Fig. 13). This will release
any loose debris into the pail. You may empty the pail again at
this point but it is not necessary as any amounts of dirt and
dust will be minimal. Close the door.
CLEANING THE SECONDARY FILTER
A secondary safety filter, located at the top of the vacuum
chamber, provides additional protection to the motor. This filter
should be checked and cleaned if necessary, when emptying
the debris pail. Simply brush filter clean. If the filter is
excessively soiled, wash in a mild detergent and let it dry
completely
before reinstalling.
A. FILTER REMOVAL
Open the door located on the front of the power unit.
Reach inside the unit and remove both locking sleeves
from the retaining hooks. Carefully pull filter down to
remove.
NOTE: NuTone model VX1040CC has two secondary
filters. Ensure to remove both filters.
B. FILTER REINSTALLATION
To reinstall the secondary filter, reverse the steps
described above.
A replacement secondary filter (part no. 10941310) may be
purchased from your local Broan-NuTone Sales Outlet. To
locate your nearest Broan-NuTone Sales Outlet, call toll
free 1-888-882-7626.
page 13
CAUTION
Operating the power unit without the secondary filter will
void the warranty.
AR0003
FIG. 13
