5
SERVICE PARTS
KEY NO. PART NO. DESCRIPTION
1 99080532 Motor
2 R99020277 Fan Blade
* R99420635 External Hitch Pin (Hairpin)
3 99271236 Lamp Socket (2 Required)
4 R99030319 Fan Switch Assembly
5 R561138 Light Switch
* K4402-000 Rectifier Assembly (Night-Light)
7 97015294 Light Lens Assembly
8 98009816 Wiring Cover
9 R99091038 Grille (Black)
R99091039 Grille (White)
R99091041 Grille (Almond)
R99091040 Grille (Biscuit)
11 R99360246 Knob (Black)
R99360244 Knob (White)
R99360245 Knob (Almond)
R99360247 Knob (Biscuit)
12 R99091071 Baffle (Black)
R99091072 Baffle (White)
R99091074 Baffle (Almond)
R99091073 Baffle (Biscuit)
13 99010316 Aluminum Filter
99010317 Non-Ducted Filter (Purchased separately)
15 97005544 3¼” x 10” Damper Assembly
16 R680508 7” Round Duct Plate
Order replacement parts by PART NO. - not by KEY NO.
* Not illustrated
16
12
11
3
7
9
4
5
8
2
13
1
15
