CLICK!
Connect the fans power cable
Das Lüfterkabel anschliessen
Connecter le câble d'alimentation des ventilateurs
Pass the display cable through the hole
Das Anzeigekabel durch das Loch führen
Passer le câble de l'afficheur à travers le trou
Connect the Modbus cable
Das Modbus-Kabel anschliessen
Connecter le câble Modbus
16
CLICK!
nVent.com
14/18
60130-922_BET Rev.A
