nvent SPECTRACOOL N36 Series User Manual

© 2022 nVent
89215758
- 16 -
DISPLAYING AND CHANGING PROGRAM SETTINGS
TO VIEW OR ACCESS THE SETTINGS
TO ACCESS FOLDER MENUS:
1. Press
button to display passcode screen, the screen displays PSd on line 1 and 0000 on line 2.
2. Press
button to access to passcode , the rst digit of 0000 is ashing and press 3 more times
until the last digit of 0000 ashes.
3. Press
arrow two times to change the 0 to 2. Press for access to folder menus.
Note: to exit the security level to the main screen wait one minute with no action or Press
arrow until LOG Out message displays, then press
button.
TO CHANGE A PARAMETER SETTING
1. Once in the folder menu navigate to the desired setting to be changed using the
arrow to scroll
and
button to access a menu or parameter.
2. To change a parameter Press
button and parameter value will begin to ash.
3. Press
/ arrow to the desire value.
4. Press
button to save the setting and the screen will revert to the parameter mnemonic.
Note: if
button is not pressed, the new setpoint is not saved.
To exit the parameter settings to the main screen wait one minute with no action or Press
arrow
few times until ESC displays, then press
button to return to UoF screen. From the UoF screen
Press
arrow few times until LOG Out message displays, then press button to return to the
main screen.
Selecting ESC returns to folder menu.
Selecting LOG out returns to main screen.
HEAT/COOL OPERATING PARAMETERS
Mnemonic Parameter Description Default Value Range
CSt
1
Cooling setpoint 80 F 72 F to 120 F
Cd (Cd1)
1
Cooling differential 7 F 2 F to 25 F
Cd2
4
Cooling differential 2 15 F
HSt
2 3
Heating setpoint 50 F 45 F to 60 F
Hd
3
Heating differential 7 F 2 F to 25 F
1 Compressor or cooling turns ON at CSt + Cd and OFF at CSt
2 Heater or heating turns ON at HSt and OFF at HSt + Hd
3 Heating mode is only applied to a unit with heater option
4 Cooling differential 2 is only applied to 2-stage compressor and lead-lag application
ALARM PARAMETERS
Mnemonic Para Description Default value
Ht High temperature alarm setpoint 125 F
Lt Low temperature alarm setpoint 40 F
dO Door open alarm setting NC
ArOP Alarm relay output NO
NOTES: (4) The alarm relay output logic is designed to be congurable
