- 6 -GV-N95T Series Graphics Accelerator
2. Hardware Installation
2.1. Board Layout
SLI Connector
TV-Out
DVI-I Connector 1
DVI-I Connector 2
TV-Out
DVI-I
Connector 1
DVI-I
Connector 2
Analog LCD Monitor Analog Monitor
or
HDTV
NTSC / PAL TV Projector
NTSC / PAL TV Projector
or
or
Pr
Pb/AV Output
S-Video Output
Digital LCD Monitor
DVI Output
DVI-I to HDMI Adapter
D-Sub
Output
HDMI TV
Y
DVI-I to D-Sub
Adapter
