3.8 S/PDIF Output Connection Header
S/PDIF (Sony/Philips Digital Interface) is a standard audio transfer le format. It is usually
found on digital audio equipment such as a DAT (Digital Audio Tape) machine or audio
processing device. It allows the transfer of audio from one le to another without the
conversion to and from an analog format, which could degrade the signal quality.
LP T
VG A
JL AN
JC61D3 C01 V1 1
170 235
.
*
CO M
FUS B2
3
BAT
1
VCC
OUT
GND
