4.5.8 JUSTw00t! Setting(OverClock Settings)
BIOS SETUP UTILITY
Main Advanced Boot Security Power JUSTw00T! Exit
OverClock Settings
ConFigur CPU
frequency and
voltage
←
Select Screen
↑↓
Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
►
AMD Overclocking Configuration
►
DRAM Timing ConFiguration
►
Memory Configuration
Memory CLK :N/A,667MHZ
CAS Latency(Tcl) :N/A,9 CLK
RAS/CAS Delay(Trcd) :N/A,9 CLK
Row Precharge Time(Trp) :N/A,9 CLK
Min Active RAS(Tras) :N/A,24 CLK
RAS/RAS Delay(trrd) :N/A,4 CLK
Row Cycle (Trc) :N/A,33 CLK
Write Recover Time(Twr) :N/A,6 CLK
CPU/LTD Spread Spectrum [200.0]
PCIE Spread Spectrum [Enabled]
SATA Spread Spectrum [Enabled]
GPU Over control [Auto]
CPU Frequency,MHZ [200.0]
MCP PCI-Express Frequency,MHZ [100]
CPU Voltage Control [Auto]
CPU Voltage :1.264v
K10 CPUNB Voltage Control [Auto]
DRAM Voltage Control [Auto]
DRAM Voltage :1.936 v
Chipset Voltage Control [Auto]
Chip Voltage :1.272v
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
►
Memory Conguration
Click <Enter> key to enter its submenu.
BIOS SETUP UTILITY
JUSTw00T!
Memory Configuration Enable Bank Memory
Interleaving
←
Select Screen
↑↓
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Bank Interleavin
Channel Inter leaving
Enable Clock to All DIMMs
MemClk Tristate C3/ATLVID
Memory Hole Remapping
DCT Unganged Mode
Power Down Enable
Page Smashing
[Auto]
[Auto]
[Disabled]
[Disabled]
[Enabled]
[Always]
[Enabled]
[Disabled]
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
• CPUFAN Mode Setting
Available options: Manual Mode
,
Thermal Cruise Mode
，
Speed Cruise Mode
• CPUFAN PWM Control
According to PWM out conguration adjustable CPU Fan speed.
